EUROPEAN BOX SUBSTATION

YBM 29 High Voltage/Low Voltage Prefabricated Substation also known as European box-type transformer substation is a high voltage electrical equipment, power transformers,low voltage electrical equipment combination in one compact with the small volume.

It is easy to move, safe and reliable operation, the beautiful shape and other characteristics, which is especially suitable for the urban public power distribution, the high-rise buildings, the residential areas, the industrial and mining enterprises, the ports, the oilfields,the parks,the stations,the airports,the subways, the highways and other power supply places and is a new type of power distribution equipment.

• Altitude: ≤1000m

• Environmental temperature: -30℃-+40℃

• The relative humidity of the air does not exceed 90% (+25℃)

• The product shall be installed in a place free from fire,explosion, serious pollution, chemical corrosive gas and violent vibration. In case of any breach of these technical conditions,the case shall be handled by the user in consultation with the manufacturer.

The box-type transformer is available in multiple structural forms, such as "MU" and "PIN" types. Its frame is welded from high-quality channel and angle steel, ensuring high mechanical strength. The enclosure is made of corrosion-resistant aluminum alloy with a clean, modern appearance that blends well with the environment. Lifting devices at the base provide convenient transport and installation.

Main reference dimensions

Note: The data in the table is subject to change without prior notice, and the product is subject to delivery.

YBM Combined transformer substation

High voltage main loop scheme
